Download a free DWG block of a double-door refrigerator with top freezer
Download a free DWG block of a double-door refrigerator with top freezer to place a standard household appliance accurately in your kitchen drawings. This CAD block is ideal for residential layouts, compact kitchens, apartment projects, and renovation work where realistic appliance planning matters.
The file includes a plan view, front elevation, and side elevation, with practical proportions close to 0.76 m wide, 0.78 m deep, and 1.69 m high. These views make it easier to check the appliance footprint, verify door swing clearance, and coordinate the refrigerator within the overall kitchen layout.
A top-freezer refrigerator is one of the most common configurations used in residential kitchens. Using a precise DWG representation helps you organize nearby cabinets, circulation space, electrical outlets, and access to cold storage areas more efficiently. The block can also be adjusted to match your project standards, including scale, layers, lineweights, and graphic style.
This DWG block can be opened and used in AutoCAD, AutoCAD LT, and AutoCAD for Mac, as well as in many compatible design programs. Native DWG-based AutoCAD alternatives include BricsCAD, ZWCAD, DraftSight, GstarCAD, progeCAD Professional, nanoCAD, and CMS IntelliCAD. It can also be integrated into BIM and architectural software such as Autodesk Revit, Archicad, Vectorworks, Allplan, and SketchUp Pro. For mechanical CAD and 3D modeling, it is compatible with SolidWorks, Autodesk Inventor, Autodesk Fusion, and Rhino 3D. If you prefer free or open-source alternatives, you can also work with the file in LibreCAD, QCAD Professional, and FreeCAD.
